X(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KW

Product Categories
Qingdao Honghesheng Industry Co., Ltd.
Contact Now

X(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KW

Brand Name : HHS

Model Number : XSN-75

Certification : CE

Place of Origin : Shandong, China

MOQ : 1 set

Price : USD10000/SET

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 300 sets/month

Delivery Time : 30 working days

Packaging Details : wood package and 20/40 GP/HC

Condition : New

Batch Time(times/hour) : 10 times/hour

Total Capacity(L) : 35L

Marketing Type : New Product 2021

Warranty : 3 Year

Core Components : PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pum

Voltage : 380V,Customer's Request,380V/50HZ

Power(w) : 55KW

Type : Rubber Kneader,Electric heating water cooling

Color : orange,Blue or Green,customized

Application : Rubber / Plastic Mixing,Mixing Rubber or Press rubber sheet

After-sales service provided : Engineers available to service machinery overseas

Weight : 6000KG

Dimension(l*w*h) : 3200*1900*2950mm

Contact Now

production

X(S)N-75 rubber dispersion kneader machine/ Banbury Mixer

X(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KWX(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KWX(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KW

parameters

Model

Item

 X(S)N-1.5 X(S)N-3 X(S)N-10x32 X(S)N-20x32 X(S)N-35x32 X(S)N-55x32 X(S)N-75x32 X(S)N-110x32 X(S)N-150x32 X(S)N-200x32
Total volume( L ) 4 8 25 45 75 125 180 250 325 440
Working volume(L) 1.5 3 10 20 35 55 75 110 150 200
Motor power ( KW ) 4 7.5 18.5 37 55 75 110 185 220 280

Tilting

Worm gear

Worm gear

Worm

gear

Worm

gear

Worm

gear

Worm

gear

Worm

gear/

Hydraulic

Worm

gear/

Hydraulic

Worm

gear/

Hydraulic

HHydraulic

Sealing

Spring type

Spring type

Spring

type

Spring

type

Spring

type

Spring

type

Spring type/ Hydraulic

Spring type/ Hydraulic

Spring type/ Hydraulic

Spring type/ Hydraulic

Rotor speed (F/R) (r/min )

8.8-88/

6.9/69

25-100/

18-72

 32/25 32/26 32/26 32/26 32/26 30/24.5 30/24.5 30/24.5

Dimension

(mm)

 L 1550 1600 2300 2500 3150 3370 3770 4060 4200 4520
W 750 950 1360 1750 2020 1950 2570 2750 3300 3400
H 1825 1880 2120 2450 2960 3020 3160 3590 3900 4215
Total weight( kg ) 750 1050 3000 4500 7200 8200 11600 15600 19500 22500

working shop show

X(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KWX(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KW

X(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KWX(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KW

We are professional manufacturer of machinery

About us--

Qingdao Honghesheng Machine Manufacture Co., LTD.

1. has specialized in machine manufacture almost 20 years;(since 1996)

2.100% real manufacture meet all your requests;

3.CE,ISO Certification;

4.provide one year quality guarantee and long-term technical support;

5.provide all kinds of rubber machine:

Vulcanizing machine,Rubber mixing mill,Rubber crushing mill,Rubber refining mill,Rubber plastices kneading machine,Rubber injection&pressure molding machine,Vaccuum heat presses to model the machine, Hydraulic press, Rubber sheeting mill,Jaw type falt vulcanizer,Prevulcanization equipment,Hydraulic tyre vulcanizer,Automatism inner tube press vulcanizer, Foaming press; Conveyor belt production line, Sidewall belt production line, Conveyor belt forming line; Batch-off cooler (cooling line); Rubber cutter etc;

6.our machine are welcome by the world,popular in lots of markets

X(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KWX(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KWX(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KW

X(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KWX(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KWX(S)N-75 Banbury Rubber Dispersion Kneader 380V 50HZ 55KW
Packaging & Shipping

For FCL goods, we usually pack machines with stretched film and then load them to the

container. to ensure safety, we will fix machine with steel .

For LCL goods, we usually pack machines with standard wood boxes first, and then they will be transported .

Our Services

1 Guarantee : 2 years ,manufacturer sell, We offer lifetime technical support

2After sales:

1 once problems appear, we will reply in 24 hours. And give solutions

2provide facory layout drawing . Engineers available to service machinery overseas; Send the engineers to debug the machines

Company Information

Qingdao Honghesheng Industry Co., LTD, manufacturer of rubber machine,which is located in the west coast of Qingdao economic district, with 10 million registered capital. The company covers an area of 5000 square meters with 26 professional and technical staffs and 5 senior engineers. The technical staffs have working experience in large tire enterprise who can design more suitable equipment for the customer as for tire production process. Also they can provide new factory site planning and other services.
The company’s main products are: Rubber kneader, rubber mixing mill, rubber sheet cooling machine, inner tube production line,tyre production line, vulcanizing press, waste tyre recycling plant…

welcome to visit our factory!

FAQ

1. Q: Are you a manufacturer or training company?

A: We are the manufacturer. We have our own plant,worker and techniques research developing department.

2 .Q: Where is your factory located? How can I visit there?

A: Our factory add is Tieshan industrial Park, Jiaonan, Qingdao, Shandong province, China.

Nearest airport is Qingdao liuting international airport

Kindly send plane information in advance, so that we can pick you up at the airport, and book hotels as you require.

3. Q: What are your hot sale machine?

A: Our rubber and plastic machines are popular in the foriengn market. And main products are tyre recyling plant ,press machine and other machine.

4. Q: How does your factory do regarding quality control?

A: Quality is priority and we have our own quality control department. We win make a strick inspectin before the machines leave the factory.

5 .Q: Are the techncal parameter is fixed?

A: Basically, each model corresponding to the related machine. But we can design different type machine according to the client’s requirement.
