XJW150 150mm Tires Cold Feed Rubber Extruder PVC Rubber Hose Making Machine

Brand Name : HHS

Model Number : XJ65-200

Certification : CE; ISO

Place of Origin : Shandong, China

MOQ : 1 set

Price : USD:20000-80000 /SET

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 50 sets/month

Delivery Time : 20 working days

Packaging Details : wood package /20-40 container

Plastic Processed : PVC, WPC, PP PE PVC WPC

Screw diamete : 65-200mm

Screw L/D Ratio : 22

L/D : 4-4.35

Voltage : 380V/50HZ or as your requirements

Dimension(L*W*H) : 2300x2500x3200

Power (kW) : 80

Weight (KG) : 3000 KG

Contact Now

XJW-150 cold feed rubber extruder

XJW-150 Cold Feed Rubber Material Extruder for Rubber Hose Making

1) Application& Features

1. The machine screw and barrel optimized design to meet the majority of users of different formulations, different process requirements.
2. Automatic feeding section design novel and practical, feeding fast and convenient and safe. This feeding design has won the national invention patent.
3. Equipped with different head, can achieve feeding, extrusion, squeeze pipe sticks, extruded profiles and other uses.
4. Where the contact with the plastic parts are water circulation, and is equipped with a thermostat-controlled water temperature control system, the selection of the appropriate water temperature, can effectively ensure the quality of extrusion of various rubber stability

Product Description

Cold feed rubber extruder

Cold Feed Rubber Extruder is applicable to extruding tires of tread in radial tire and cross-ply tire preparation, extruding bead apex, covering rubber of electric wire, electric cable and rubber hose, extruding rubber board, slab, conveyer belting and rubber core. Also the extruder is widely used for feeding rubber on steal cord calendaring line, feeding rubber for radial tire’s airtight seal.

The material of all screw shafts and liners is 38CrMoAlA high-quality steel, the surface of them is processed by nitrogen treatment and the hardness HRC is 60-65. Their resistance to wear and corrosion is very good. The direct current motor is applied to infinite speed variation in transmission agent. Reduction is a hard tooth face cylinder gearwheel reducer. The transmission is stable and reliable. The agent has small volume and low noise.

The extruder uses the technology of room temperature feeding. Its advantages are high quality, high yield ability, high efficiency and energy conservation. Also the extruder can extruder rubber at low temperature, and is highly adaptable to processes of tires of rubber sizing material. The extruder is the first choice machine while technology innovating, process improving and equipment replacing in rubber industry.

model	XJ-65	XJ-85	XJ-115	XJ-150	XJ-200
diameter of screw(mm)	65	85	115	150	200
ratio of screw(L/D)	1:4	1:5	1:4.8	1:4.4	1:4.4
max speed of screw(r/min)	20-47	27-80	20-60	27-81	22-67.2
power of main motor(kw)	7.5	17	22	40	55(75)
max output(kg/h)	50-80	62-270	100-420	700	1400
overall size(mm)	1600x675x1208	2050x735x1275	2300x800x1370	3585x814x1470	4549x1140x1750
weight(kg)	1500	2000	3300	4500	7200

XJW150 150mm Tires Cold Feed Rubber Extruder PVC Rubber Hose Making Machine

Detailed image
