CE ISO9001 4L/D To 4.35L/D Rubber Grinding Machine Rubber Extruder For Band

Brand Name : HHS

Model Number : XJ65-200

Certification : CE; ISO

Place of Origin : Shandong, China

MOQ : 1 set

Price : USD:20000-80000 /SET

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 50 sets/month

Delivery Time : 20 working days

Packaging Details : wood package /20-40 container

Plastic Processed : PVC, WPC, PP PE PVC WPC

Screw diamete : 65-200mm

Screw L/D Ratio : 22

L/D : 4-4.35

Voltage : 380V/50HZ or as your requirements

Dimension(L*W*H) : 2300x2500x3200

Power (kW) : 80

Weight (KG) : 3000 KG

Contact Now

High Quality Rubber Extruder /Rubber Band Machine/ Rubber Grinding Machine With CE ISO9001 New Price

1. Product Application

The Extruder is consist of screw,machine barrel,headpiece,fixing patter device,pulling device ,cutting device,batching device and transmission device and control system, the headpiece is extrusion mould. It is mainly applied to extrude rubber and plastic products.

This rubber extruder is superior quality, dependable performance.
And it is main used for extruding tube, hose.

This rubber extruder of hot feeding and single screw extruding, with adjustable speed. Changing the head of the machine can obtain various extruding, semi-finished products and forming sheets and filter rubber for coating. It can be used widely in extruding.

Rubber Extruder.

Full automatic, constant tension and unattended
Smooth surface, no bubbles inside, precise size
Low rubber temperature, high capacity, good plasticization, low power consumption
Good plasticizing effect on high strength conveyor belt
rubber temperature controlling easily
More and more excellent
Linear bearing rubber feeding head
It's very convenient for product removing and mold replacing.

Technical parameter
Model	XJ-65	XJ-85	XJ-115	XJ-150	XJ-200
Screw outer diameter	65	85	115	150	200
Length-diameter ration	4	4.3	4.8	4.43	4.35
Product capacity(kg/h)	50-80	70-210	100-420	700-1200	1500-2200
Motor power(kw)	7.5	11/15	22	18.3-55	25-75
Size	16306041050	20507001200	16306041050	34118141470	45641800150

2. Main Features

1) The cold feed rubber extruder is simple structure ,easy in installation and maintenance.
2) The cold feed rubber extruder adopts advanced world famous brand components in hydraulic parts ,electric parts and operation parts.
3) The cold feed rubber extruder is energy saving, high productivity , good plasitcization and refined glue quality characteristic.
4) The cold feed rubber extruder can be equipped with various extrusion heads as required by users.
5) A machine body temperature measuring and indicating device is installed.The feeding zone is equipped
with side rolls for the enhancement of feeding capability.6) The screws and bushes are subjected to nitrogenation treatment to get enough strength and wear-resistance.
 7)The reducer has a forced lubrication unit,which is featured by high transmission efficiency,long service life and low noise.
 8) The machine is driven by a variable-speed motor.
 9) The side rolls are designed as side-open type for easy rubber removal.
10) ISO, CE, SGS, GOST certificate.
The machine can be used to extrude various rubber products.Just tell us your work needs, we make proposal and quotation for you.
